Easy-to-use operation interface
Intelligent component design meets the needs of various experiments

Easy-to-use operation interface

(1) 7-inch high resolution LCD touch screen

(2) Several languages available: Chinese and English;

(3) Data export flexibility: support USB data transmission, easy data transmission and processing

(4) Measurement data can directly export to Excel for futher analysis

(5) Various testing programs can be preset, single plate can be tested for a number of different inspection items.

Intelligent component design meets the needs of various experiments

1) Equipped with two channels, with the ability to quickly analyze two kinds of fluorescence signals of a sample;

(2) A variety of optical channels are optional, suitable for different ssDNA and dsDNA, RNA, protein detection experiments;

(3) Open system: In addition to the standard reagents, it can also match most of the fluorescent detection reagents on the market; The sample tube is replaceable and can be selected in different sizes (0.5mL/0.2mL);

(4) Fast detection, fluorescence detection can be completed within 3 seconds

Application direction

Fluorometers are especially suitable for:

(1) Your sample is very rare and difficult to process

(2) Extracted dsDNA, oligos, RNA or a very small amount of protein

(3) The sample will be used in expensive downstream experiments: qPCR, PCR cloning, transfection and next-generation sequencing and other precision assays

Working process

Application field

360 Excitation wavelength

Nucleic acid quantification, plant GUS reporter gene detection, β-galactosidase activity detection, cell apoptosis detection
470 Excitation Wavelength

DNA, RNA quantification, green fluorescent protein GFP, gene detection, fluorescein detection, protein quantification, bacterial proliferation detection, Pgp activity detection, multidrug resistance (MDR)
525 Excitation Wavelength

Red fluorescent protein RFP gene detection, rhodamine detection, enzyme activity detection, cell activity toxicity detection, Cy-3 fluorescent labeling detection
625 Excitation Wavelength

RNA quantification, Cy-5 fluorescent labeling detection

360 Excitation wavelength

Nucleic acid quantification, plant GUS reporter gene detection, β-galactosidase activity detection, cell apoptosis detection

470 Excitation Wavelength

DNA, RNA quantification, green fluorescent protein GFP, gene detection, fluorescein detection, protein quantification, bacterial proliferation detection, Pgp activity detection, multidrug resistance (MDR)

525 Excitation Wavelength

Red fluorescent protein RFP gene detection, rhodamine detection, enzyme activity detection, cell activity toxicity detection, Cy-3 fluorescent labeling detection

625 Excitation Wavelength

RNA quantification, Cy-5 fluorescent labeling detection

Product parameters

Performance Features

Light source

LED
Dynamic range

5 orders of magnitude
Measurement speed

<3s(single time)

Standard channel

Channel

Excitation wavelength

Emission wavelength
Blue

470nm

525nm
RED

625nm

690nm

Optional channel

Channel

Excitation wavelength

Emission wavelength
UV

365nm

460nm
GREEN

525nm

620nm

Common reagents and application

Excitation wavelength

Commonly used fluorescent reagents

Applications
365

Hoechst33258, 4-MU,EnZCheK Caspase

Plant GUS report gene detection, cell apoptosis detection
470

PicoGreen®, oligreen，RiboGreen®, GFP, Protein, Fluorescein, Quant-iT™

DsDNA,ssDNA quantitative, green fluorescent protein (GFP), fluorescent detection, protein quantitative
525

Rhodamine, Cy3, RFP Vybrant Cytotoxicity

Rhodamine detection, Cy-3 fluorescence labeling detection, red fluorescent protein (RFP) gene detection, cell activity toxicity detection
625

Cy5, Quant-iT RNA

Cy-5 fluorescence labeling detection, RNA quantitative
